SoundCraft Ui16 User Manual

Ui12, Ui16 User Manual
7.0: FX EDIT
FX EDIT
7.0: FX EDIT
Digital FX are used in all types of audio to help create depth and colour to a mix. The Ui12 has three
internal Lexicon FX processors: Reverb, Delay, and Chorus. The Ui16 has an additional processor that
can either be an additional reverb or delay.
There are dedicated FX Sends and Returns for the internal FX - simply adjust the corresponding FX
Send level and bring up the level of the FX Return channel to incorporate FX into your mix.
See section 4.4 for more details of FX Sends.
FX Edit panels have Preset Save / Recall, and Fader-based parameter adjustment with numeric LCD-
style numeric display.

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
