SoundCraft Ui16 User Manual

Ui12, Ui16 User Manual
10.0: SETTINGS
SETTINGS
10.0: SETTINGS
RECORD MODE
32-bit, 24-bit, 16-bit
Choose a sample rate for the media recording function.
GUI PERFORMANCE
FRAME RATE
FULL, 1/2, 13, 1/4
Choose the highest frame rate that your device can reproduce for best performance.
DISABLE RESCALING
ON, OFF
Enable/Disable display rescaling. Disable this if your display is struggling with GUI movements..
DISABLE LED METERS
OFF, ON
If you are using a slower CPU, you may wish to turn off the LED channel meters to reduce CPU usage.
LOCAL
MASTER LOCK
ON, OFF
When ON, the Master Channel fader is locked in place. Other parameters are still changeable.
METER QUANTISATION
OFF, ON
Choose between quantised metering - rather like an LED bargraph - or non-quantised (continuous).
FADERGLOW
OFF, THIN, NORM
Options for the coloured lines under the faders. 1. On, 2. Thin and 3. Off. These lines are handy to quickly see which
group of faders you are viewing (blue for FX, orange for AUX, and so on).
HIDE COMP/GATE
OFF, ON
When off, the channel meters include shorter red LED gain reduction metering below the primary meters.
DIM LED METERS
OFF, ON
Turn on to lower the intensity of the metering colours.
DISABLE VU INPUT LEVEL
OFF, ON
Disable/Enable the blue VU input level meters.
DISABLE VU PEAK
OFF, ON
Disable / Enable the peak indicators for VU meters..

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
