(2) Chassis Cooling Fan
Some chassis also feature a cooling fan. This Motherboard features a
CHAFAN connector to provide 12V power to the chassis fan. Connect the
cable from the chassis fan to the CHAFAN 3-pin connector. Install
according to the following pin assignment:
Note: CPUFAN must be installed for this Motherboard, CHAFAN is
optional.
2-3.3.6 AGP VGA Card
Insert the AGP VGA card into the AGP slot. Then connect the monitor
information cable to the AGP card back plane external connector.
SENSOR
12V
GND1
3
2
Chassis Cooling Fan
CHAFAN Pin Assignment
