SPE EXPERT 1.5K-FA TAURUS - 15.5 BAND DATA Interface; Ten - Tec, Flex-Radio, Elecraft; CAT RS232 Interface

User manual
Expert 1.5K-FA
TAURUS
INDEX Page. 44 of 92
15.5 BAND DATA Interface
Using Band Data, instead of CAT, use the four digital signals (Band A, Band B, Band C,
Band D) from the transceiver. Refer to the transceiver’s manual.
12.6 Ten – Tec, Flex-Radio, Elecraft
CAT RS232 Interface
The radio connector may be a DB-9 or DB-25 male connector or female connector (read
specific manual). Verify from the manual if the RTS–CTS link is required.
4
3
2
1
5
6
7
8
9
12
13
14
11
10
15
GND
GND
RADIO
CONNECTOR
DB15 M
RX 232
TX 232
TX 232
RX 232
RTS
CTS
(RXD)
(TXD)
.
4
3
2
1
5
6
7
8
9
12
13
14
11
10
15
GND
RADIO
CONNECTOR
GND
DB15 M
BAND A
BAND B
BAND C
BAND D
BAND A
BAND B
BAND C
BAND D
