User’s manual EXPERT 1K-FA
Pag. 34 of 76
BAND DATA Interface
4
3
2
1
5
6
7
8
9
12
13
14
11
10
15
GND
RADIO CONNECT
O
GND
DB15
M
BAND A
BAND B
BAND C
BAND D
BAND A
BAND B
BAND C
BAND D
Without the CAT, the band is commanded by four digital signals (Band A, Band B,
Band C, Band D). Refer to the specific manual.
12.6 TEN–TEC, FlexRadio, ELECRAFT
CAT RS232 Interface
4
3
2
1
5
6
7
8
9
12
13
14
11
10
15
GND
GND
RADIO CONNECTOR
DB15 M
RX 232
TX 232
TX 232
RX 232
RTS
CTS
(RXD)
(TXD)
The radio connector may be a DB-9 or DB-25 male connector or female connector (read
the specific manual). Verify from the manual if the RTS–CTS link is necessary.
RADIO CONNECTOR
