17. CHARACTERISTICS / SPECIFICATIONS
- The smallest in the world
Built-in Power supply and Automatic Antenna Tuner.
Dimension: w 28, h 14, d 32 cm. (11.02” W, 5.51” H, 12.60” D) (connectors
included).
Weight: approx. 20 Kg (19 Kg typ.), 44 lbs (41.8 lbs typ.).
- The most technologically advanced in the world
Two CPUs are used, one of which is dedicated to the transceiver interface
requirements (CAT).
Pi-L output circuit.
Over 13000 lines of software for performance that cannot be found in any other
amplifier.
- Fully Automatic
Easy connection with all models "ICOM, YAESU, KENWOOD, TEN-TEC,
FlexRadio ELECRAFT" for immediate management of the bands, tuner and
antennas.
Same performance with all makes or homemade rigs.
The operator has only to move the “Frequency Tuning Knob” in the transceiver!!!
- Wide frequency coverage
1.8 MHz to 50 MHz including WARC bands.
- Fully solid state
1 KW pep SSB output; 900 W pep CW out (typ.) ; 700 W pep out. (typ.) on
50 MHz.
FULL / HALF power selected according to the operator SSB/CW power
requirement, for digital modes and for linear protection (automatic).
No heating time, immediately ready!
Virtually limitless life of the amplification devices (MOSFETs).
- Automatic Antenna Tuner built-in
Capable of matching 3:1 SWR on HF, and 2.5:1 SWR on 6 meters.
Capable of programmable switching of 4 antennas (SO239 connectors).
Up to two antennas for the same band.
Bands, Antennas, Tuning conditions are changed in 10 msec.
Bands, Antennas and Tuning conditions are managed also in “STBY“ to support
the exciter only.
- SO2R.
- Two inputs available.
SO239 connectors.
- High power gain (up to 16 dB).
In “OPERATE“ the required drive power is automatically set with an ALC
connection and in “STANDBY“ the exciter is then automatically reset to full power.
- Very clean and low distortion output!
Spurious emissions less than -50 dB ( 50 MHz –60 dB ).
3rd order distortion (two tone test) 36 dB typ.
