User’s manual EXPERT 1K-FA
Pag. 40 of 76
14.4 5V TTL YAESU INTERFACE
4
3
2
1
5
6
7
8
9
12
13
14
11
10
15
GND
TX
RX
TTL INTERFACE
PC
GND
TX
RX
TTL
YAESU
RADIO CONNECTOR
DB15
M
RX TTL
TX TTL
X
GND
The links on the linear connector side are the same.
On the other end of the cable it is necessary to link only GND and RX TTL.
