User’s manual EXPERT 1K-FA
Pag. 38 of 76
14. TRANSCEIVER CONTROLLED WITH A PC
If the transceiver is controlled with a PC using the CAT utility, the link with the amplifier
can be made as described in the following paragraphs.
Note: BEWARE, SPE assures only the direct connection between the Linear and the
Transceiver. The use of external control software could create malfunctions that must
be resolved by the provider of such software.
14.1 ICOM CI-V INTERFACE
CI-V
INTERFACE
CT 17
ICOM
RADIO
DB15 F
LINEAR
CONNECTOR
The plug from the amplifier has to be connected to a CI–V port of the CT17 or similar
device. The transceiver has to be connected to another CI–V port.
