User’s manual EXPERT 1K-FA
Pag. 39 of 76
14.2 RS232 INTERFACE
4
3
2
1
5
6
7
8
9
12
13
14
11
10
15
GND
TX
RX
GND
KENWOOD
OR
YAESU
RADIO CONNECTOR
PC CONNECTOR
TX
RX
RS232
RS232
DB15
M
RX 232
TX 232
X
GND
This type of link is the same for KEWOOD, YAESU, TEN-TEC, FlexRadio and
ELECRAFT
On the other end of the cable it is necessary to link only GND and RX 232.
14.3 5V TTL KENWOOD INTERFACE
4
3
2
1
5
6
7
8
9
12
13
14
11
10
15
GND
TX
RX
TTL INTERFACE
PC
GND
TX
RX
TTL
KENWOOD
RADIO CONNECTOR
DB15
M
RX TTL
TX TTL
KEN TTL
X
GND
The links on the linear connector side are the same.
On the other end of the cable it is necessary to link only GND and RX TTL.
