User’s manual EXPERT 1K-FA
Pag. 69 of 76
In the following picture can be seen, as an example, the
Power
Control
(
15%
) setting
relative to the same band (20 m), but using the HALF mode selection instead.
Once adjusted the proper preset, go to TX mode (RTTY, CW) to verify the output power
ATTENTION! It is strongly recommended to start with a low preset value (e.g. 10) and
progressively increasing it; this is to avoid the linear overdriving.
The output power levels to reach are about 900 W (FULL mode) e 500 W (HALF mode).
The following empty table could be useful as a template for the FlexRadio user’s Power
Control presettings.
Band 160 m 80 m 40 m 30 m 20 m 17 m 15 m 12 m 10 m 6 m
HALF
FULL
