| Functionality | 35
Start pixel index Parameter width [bit] Parameter Description
4 32 Counter 0 Value
8 32 Counter 1 Value
12 32 Counter 2 Value
16 32 Counter 3 Value
20 32 Timer 0 Value in units of clock
cycles
24 32 Timer 1 Value in units of clock
cycles
28 32 Timer 2 Value in units of clock
cycles
32 32 Timer 3 Value in units of clock
cycles
36 24 Integration Time in units of clock
cycles
40 24 Reserved
44 32 Reserved
48 12 Image Average Value("raw" data
without considering gain settings)
52 12 Horizontal start position of ROI
(OffsetX)
56 12 Image Width
60 12 Vertical start position of ROI
(OffsetY). In MROI-mode this
parameter is the start position of the
first ROI.
64 12 Image Height
68 2 Digital Gain
72 12 Digital Offset
76 16 FineGain. This is a fixed-point value
in the format: 4 digits integer value,
12 digits fractional value.
80 1 Line Input Level
84 16 Electronics Type Code
88 32 Electronics Serial Number
92 32 Spectral camera serial number
96 32 Custom value 1: value of register
StatusLineCustomValue1 that can be
set by the user
All rights reserved - Specim, Spectral Imaging Oy Ltd.
