| Technical Information | 47
Characteristics Value
Shutter Electromechanical shutter for
dark background registration
Order blocking filter yes
Table 11: Camera Performance Characteristics FX10c
Characteristics Value
Detector type CMOS
Slit width Physical width 42 µm. Projection
on sensor 32 µm (M~1/1.3)
Pixel size 16x8 µm
# Spatial pixels 1024
Binning (spectral x spatial) 2 x 1
Spectral binning options 2x 4x 8x
# Spectral bands covering the specified range 70 35 17.5
Spectral sampling/pixel 2.7 5.5 10.8
Spectral resolution FWHM 5.5 nm (mean)
SNR @ max. signal 420:1
Frame rate (fps), full range (140 bands) max. 514 FPS
Frame rate (fps) examples 70 bands = 985 FPS
35 bands = 1813 FPS
1 band = 9900 FPS
Integration time Adjustable, within frame time
Sensor cooling Passive
Shutter Electromechanical shutter for
dark background registration
Order blocking filter yes
For more information on maximum frame rates, refer to Technical Note: Maximum frame rates in FX10/FX10e and
FX17/FX17e.
Mechanical Specifications
This section describes the mechanical specifications of the camera.
Table 12: Mechanical Specification
Characteristics Value
Housing Painted aluminium case
All rights reserved - Specim, Spectral Imaging Oy Ltd.
