| Description | 8
Serial number Camera version
8xxxxxx FX10ce
Firmware version and updater
With the new revision of FX-series it is now possible to update the camera firmware via software updater on-site with
the software package provided by Specim.
Note: It is not possible to use this feature previous revision’s FX-cameras without hardware changes.
See the camera's serial number to check if your camera belongs to the new revision: the third digit of the old revision
is xx0xxxx, while the new revisions' serial number is xx1xxxx.
Camera data path
A diagram of the camera data path is shown in the figure below.
Figure 5: Camera data path
Feature Overview
Feature Characteristics
Image sensor CMOS
Data interface
• Camera Link in FX10 and FX10c
• GigE in FX10e and FX10ce
Operating range
• 400 to 1000 nm in FX10 and FX10e
• 400 to 780nm in FX10c and FX10ce
Image enhancement
• Offset and hot pixel correction
• Automatic Image Enhancement (AIE)
Image size reduction Multiple Regions of Interest (MROI)
Trigger modes Opto isolated trigger input and opto isolated strobe
output
Image Correction
The camera includes the following image corrections:
• Offset and hot pixel correction
• Automatic Image Enhancement (AIE) means that spectral calibration will be the same for every FX camera, and
that smile and keystone will be corrected to practically zero for all cameras.
A customer with several cameras can replace one camera with another and still have the same spectral calibration
and smile/keystone without additional calibration.
All rights reserved - Specim, Spectral Imaging Oy Ltd.
