Spectra Precision Focus 30 User Manual

3 Getting Started
24 Spectra Precision FOCUS 30 User Guide
Control Unit Face2
The Face2 control unit is a graphical display with a built-in backlight and four control
buttons.
Fig. 3-11 Face2 display
Function Description
U Change Face
N Scroll Up
O Scroll Down
P Enter
When a secondary function is available for the keys (N, O or P), an icon
appears
at the bottom of the display. To access the secondary function, press the appropriate
key.
A long press with the key U starts the Control Unit
Face2 Backlight. Without any
actions Backlight turns off after 30 seconds.
Note – When the field software is running, the trigger key performs the same function
as the Measurement1 key (
M ) on the Face1 side and the Enter key ( P ) at the Face2
side.
