Spectra Precision FOCUS 30 User Guide 59
4 Setup
Fig. 4-48 Vertical adjustment directions
Counter clockwise = up
Clockwise = down
3. To correct the horizontal position of the laser spot, insert the allen key into the
horizontal adjustment port and turn it as shown in Figure 4-49.
