6.9 Activating/Deactivating Standby mode

PressandreleasetheMENUbuttonattheStandardDisplayandselectStandby(Pic31).

Pressing and releasing button 4 activates the Standby mode.

Theself-levelingwillbestoppedandthebeamwillbeturnedoffwhiletheHIalertisstillactive.

ThedisplayshowsthestandbysymbolandtheLevel/StandbyLEDashesredevery5seconds.

To deactivate Standby mode and restore full operation of the laser, press and release button 4.

6.10 Start Reference Check

Whenworkingduringtemperaturechangesandoverlongdistancestheproductrequiresafrequent

reference check to maintain accuracy and avoid errors caused by drift. The transmitter will do an

automaticuponstartupandafter20minutesofoperation.Itwillrepeatthereferencecheckevery

60minutesandwhenthereisa5°C(9°F)changewithintheproduct.Whencarryingoutworkwhere

accuracy is paramount it is advised to manually prompt a reference check at regular intervals.

  PressandreleasetheMENUbuttonattheStandardDisplayandselectReferenceCheck

  (Pic35).

Pressing and releasing button 4startstheReferenceCheckconsideringthecurrenttemperatureinside the

housing.Whiletherotorchecksthecorrectpositiontherotationwillbestopped.

Note:Agradevaluehastobeenteredbeforetheunitstartsthereferencecheck.

6.11 Setting Menu

PressandreleasetheMENUbuttonattheStandardDisplayandselectSettings(Pic36).

Press and release button 4toopentheSettingMenu;selectthedesiredfunctionthenpressbutton

4toopentheselectedsubmenufunctionORstarttheselectedfunction.

PleaseseetheSettingMenudetailsattheendoftheuserguide.

6.12 Info

PressandreleasetheMENUbuttonattheStandardDisplayandselectInfo(Pic37).

Buttons6/7canbeusedtotogglebetweenUL,RCandRuntime.

Press and release button 4toconrmtheselection.

TheUL/RCinformation(softwareversion,ID,etc.)ortheruntimeoftheULwillbedisplayed.

Pic 34

Standby

Pic35

Reference

Check

Pic36Settings

Pic37Info

Pic38InfoUL Pic39InfoRC

Pic40Runtimes
