Spectra Precision Trimble UL 633N User Manual

23
11 SF601 - User Guide
SF601attachedtoagraderod
using the standard receiver clamp
Components SF601
SF601attachedtothe
optional pipe laser target base
1. SF601
2. Slider
3. CenterHole
4. PowerButton
5. BubbleVial
6. BatteryLED
7. ModeLED
8. RedDirectionLEDs
9. IRtransmitters/receivers
10. Markingnotches(frontandback)
11. M6ClampMount
12. Batterydoor
13. LatchforBatteryDoor
14. ReleaseTabSlider
10
1
10
3
4
5
9
10
7
6
10
10
5
8
12
11
10
13
2
2
14
