Spectra Precision Trimble UL 633N User Manual

20
8.11 Password On/Off
SelecttheSetPasswordON-Officon(Pic92)andpressandreleasebutton4 to open the Password
menu.Buttons6/7canbeusedtotogglebetweenPasswordOn(Pic93)andPasswordOff(Pic
94)ifaPasswordhasbeenenteredbefore.Pressandreleasebutton4toconrmtheselection.
Pic 93 Password
On
Pic 94 Password
Off
8.12 Radio (RF) Channel
IntheRFChannelmenutheusercanchangetheradiochannel.Thismayhelptoovercomesome
radioconnectivityissuesbasedonheavyradiotrafcatthejobsite.Inthemenu“Settings”(Pic59)
selecttheRFChannelicon(Pic95)andpressandreleasebutton4toopentheRadioChannel
menu(Pic95).TheRFchannelselectiondialogcontainssixradiochannels.Chooseonechannel
andpressandreleasebutton4toconrmtheselectedradiochannel.
Note:AfterchangingtheRFchannel,theRC,HLandSTneedstobepairedagain.
Note: To achieve the best radio performance, it is recommended to use the products in a height of app. 1m
using a tripod or similar items.
8.13 Select Language
SelecttheLanguageicon(Pic96)andpressandreleasebutton4 to open the Language menu.
Usebutton5 to 8toselecttherequiredlocallanguage(EN,DE,IT,FR,ES,PT,NL,DA,NO,
SV,FI,PL,TR,CZ).Pressandreleasebutton4tostoretheselectedlanguage;unitfallsbackto
the standard menu.
8.14 Position Info
Whenworkingwithhighgradevalues(>10%)oratextremetheproductrequiresthepositioninfoto
maintain accuracy and avoid errors caused by different gravity. The user has the chance to provide
thepositioninfoofthejobsitetotheproduct.Thisisthedegreeoflatitudeaswellasthealtitude.
ChooseMenuSettings(Pic59)andnavigatetothesubmenuPositionInfo(Pic97).Pressbutton4toactivate
thesubmenu.With buttons1 and2the differentvaluescan be increased/decreased.Also ‘+’or‘-‘ forthe
latitudecanbechangedwithbuttons1and2.Withbuttons5,6,7and8thecursorpositioncanbechanged.
Note:Torestorethedefaultvaluescrolldownwitharrowbuttons5or8to‘Defaultposition’.Pressbutton1
(‘Set’);theunitwillchangethesettingstothedefaultvalues.Pressbutton4toconrmthechange.
Pic92Password
On/Off
Pic95
RFChannel
Pic96
Language
Pic97
PositionInfo
