Spectra Precision Trimble UL 633N User Manual

4
4 HOW TO USE THE LASER SYSTEM
4.1 POWERING THE LASER
4.1.1 Batteries
WARNING
Ni-MHbatteriesmaycontainsmallamountsofharmfulsubstances.Besuretochargethebatterybeforeusing
itforthersttime,andafternotusingitforanextendedlengthoftime.Chargeonlywithspeciedchargers
accordingtodevicemanufacturer‘sinstructions.Donotopenthebattery,disposeofinreorshortcircuit;it
mayignite,explode,leakorgethotcausingpersonalinjury.Disposeinaccordancewithallapplicablefederal,
state,andlocalregulations.Keepthebatteryawayfromchildren.Ifswallowed,donotinducevomiting.Seek
medical attention immediately
4.1.2 Recharging the Batteries
ThelasermightbeshippedwitharechargeableNi-MHbatterypack.
Note: TheapproximatechargeofthebatteriesisshownatthelefttopsideoftheLCD.
Thechargerrequiresapprox.10hourstochargeemptyrechargeablebatteries.
Forcharging,connecttheplugofthechargertotherechargejackofthebatterypack.
Neworlong-timeout-of-userechargeablebatteriesreachtheirbestperformance
afterbeingchargedandrechargedvetimes.ForIndoorapplicationsthecharger
can be used as a power supply for the laser.
Alkalinebatteriescanbeusedasabackup.Insert4D-cellbatteriesnotingtheplus(+)andminus(-)diagrams
inside the battery housing.
The batteries should only be charged when the laser is between 50° F and 104° F (10°C to
40°C). Charging at a higher temperature may damage the batteries. Charging at a lower
temperature may increase the charge time and decrease the charge capacity, resulting in
loss of performance and shortened life expectancy.
4.2 RC603N Radio/IR Remote Control
4.2.1 Powering the RC603N
1. Open the battery door using a coin or similar pry device to release
thebatterydoortabontheRC603N. RC603Nwillbeshippedwith
alkalinebatteries.Rechargeablebatteriescanbeusedoptionalbut
needtobechargedexternally
2.InserttwoAAbatteriesnotingtheplus(+)andminus(-)diagrams
inside the battery housing.
3.Close the battery door. Push down until it “clicks” into the locked
position.
4.2.2 Turning On/Off the RC603N
Theradio/IRremotecontrolisahand-helddevicethatallowsyoutosendoperationalcommandstothelaser
from a remote location.
Pressthepowerbuttontoturnontheradioremotecontrol.Thesymbol“ ”andadditionalverticalbarsappear
in the right corner of the remote’s top display line indicating the radio connection status between the laser and
theremotecontrol.IftheRC603Nisoutsidetheradiooperatingrangetheremoteswitchesautomaticallyinto
theIRconnectioncapability.
Note:Whentheremotecontrolisinitiallyturnedon,thestandarddisplay(modelnumberandsoftwareversion)
appearfortherst3seconds,thentheaxessymbolsandlast-enteredgradeforeachaxisappearintheLCD.
Witheverybuttonpress,theLCDbacklightisactivatedandturnsoffautomaticallyifnobuttonispressedfor
8seconds.
To turn off the radio remote control, press the power button for two secounds.
Note:5minutesafterthelastbuttonpress,theremotecontrolturnsoffautomatically.
