5. With the switches chosen, the switch position boxes appear beneath each switch. Touch
the position boxes to make the switch “active” or “inactive” in the given position.
• A solid box indicates an “active” switch position.
• An open box indicates an “inactive” switch position.
• The heavy grey line under the position box indicates the current position of the
switch.
6. Touch the box under Relation to change the relationship desired between the
chosen switches.
• Choosing AND requires both switches to be in the chosen configuration to activate.
• Choosing OR allows either switch to control the action, regardless of the other
switch position.
The Status slider gives a visual indication of whether the combo switch is active or inactive.
After the setup is complete, the combo switch can be chosen in the switch field of
various functions in the transmitter.
