To balance the servo output on a given channel:
1. Touch BALANCE in the ribbon at the top of the Servo Setup menu.
2. Select the desired channel to adjust.
3. Touch one of the seven values displayed below the curve. The number value is
highlighted along with the corresponding point on the curve.
4. Adjust the value using the + or – buttons. The values for each point range from
-74 to 74. Touch CLEAR ALL to reset all values to 0.
5. Touch the back arrow (
) or select another option in the Servo Setup ribbon to
exit Balance.
The Balance menu does not scale with travel or trim and the points
are at fixed locations on the range of travel.
