GIMBAL ADJUSTMENT SCREWS
1
4 5
5 4
16
6
6
6
32
23
1 Centering
2 Ratchet Set
3 Tension Set
4 Vertical Spring Tension
5 Horizontal Spring Tension
6 Throttle Limit Switch
