RATCHETED THROTTLE
If desired, disengage the smooth throttle strap and engage the ratcheted throttle,
using a small Phillips screwdriver.
1. Back the set screw out on the smooth tension strap until the throttle moves
freely.
2. Tighten the set screw on the ratchet until it engages the gimbal.
3. Adjust the ratchet tension by turning the set screw clockwise to tighten or
counterclockwise to loosen.
NOTICE: Overtightening a screw can damage the spring. Loosening a screw
too far can cause a spring to fall out in the transmitter and possibly damage the
circuitry within.
