SPX FLOW W70 Series User Manual

Waukesha Cherry-Burrell
®
Brand W70 Series Mix Proof Valves Parts Lists
10/2023 95-03087 Page 41
W71 Mix Proof Seat Lift Valve
Notes:
* Recommended Spare Parts
2. For one-piece body, qty. 2 are required for item 6 and item 18; for a clamped body, qty. 3 are required.
3. For valve with Tef Flow
®
P design stem only.
4. Unless otherwise noted, quantity required is 1.
6. POA = Part # on availability; N/A = not available with this design.
7. Part number includes lower stem and stem bushing, which are assembled together.
Item # 1-1/2" 2" 2-1/2" 3" 4" 6" Notes
1 Control Top
3 Actuator
* 4 O-ring, Inner Stem Nitrile
N70010 N70010 N70111 N70111 N70111 N70111
* 5 Bearing, Upper Adapter
102757+ 102757+ 106047+ 106047+ 106047+ 101995+
* 6 O-ring, Body EPDM
E70223 E70228 E70232 E70236 E70244 E70258
FKM
V70223 V70228 V70232 V70236 V70244 V70258
8a Stem, Upper 111042+ 111014+ 111052+ 111022+ 111049+ POA
8b Stem, Upper, Tef Flow® P Design 134824+ 130422+ 130423+ 130421+ 132241+ POA 3
* 10a EPDM
106031+ 102736+ 107048+ 102488+ 102491+ 102738+
FKM
107990+ 107980+ 107982+ 107974+ 107977+ 108020+
* 10b Seat Ring Insert- Upper Tef Flow® P
130231+ 130232+ 130233+ 130234+ 130235+ POA 3
11 EPDM
106041+ 107693+ 107696+ 107697+ 102490+ 102737+
FKM
107992+ 107984+ 107987+ 107988+ 107976+ 108019+
12a EPDM
106036+ 107693+ 102487+ 102489+ 102492+ 102739+
FKM
107991+ 107984+ 107973+ 107975+ 107978+ 108021+
* 12b Seat Ring Insert - Lower Tef Flow® P
130243+ 130244+ 130245+ 130246+ 130247+ POA 3
* 14a Quad Ring, Lower EPDM
122689+ 35413+ 34429+ 117561+ 116952+ 122350+
FKM
122690+ 35414+ 35415+ 117562+ 116953+ 122351+
* 14b EPDM
116186+ 116188+ 116190+ 116195+ 116199+ POA
FKM
116187+ 116189+ 116191+ 116196+ 116200+ POA
* 15 Bearing, Lower Seal Retainer
101947+ 102000+ 106049+ 106048+ 102003+ 102004+
16 Stem, Lower Assembly 118247+ 118248+ 118249+ 118250+ 118251+ POA 7
16b Stem, Lower, Tef Flow® P Design 131694+ 131695+ 131696+ 130420+ 131697+ POA
16b.1 Lower Balancer, Tef Flow® P Design 128919+ 128920+ 128921+ 127704+ 128923+ POA
EPDM
E70210 E70217 E70217 E70217 E70217 POA
FKM
V70210 V70217 V70217 V70217 V70217 POA
17a Seal Retainer, Quad Ring 106066+ 106067+ 106068+ 106069+ 106070+ 125047+
17b Seal Retainer, Wiping Stem Seal 117444+ 117445+ 117446+ 117447+ 117448+ POA
18 Clamp 119-30 119-33 119-34 119-51 119-87 119-123 2
20a Adapter, O-ring or Quad Ring 111043+ 111017+ 111196+ 111026+ 111029+ 123970+
20b Adapter, Wiping Stem Seal 117840+ 117841+ 117842+ 117843+ 117878+ POA
* 21a O-ring, Upper Stem EPDM
E70210 E70210 E70214 E70214 E70214 N/A
FKM
V70210 V70210 V70214 V70214 V70214 N/A
* 21c Quad Ring, Upper Stem EPDM
121300+ 121300+ 124163+ 124163+ 124163+ 114221+
FKM
124088+ 124088+ 121299+ 121299+ 121299+ 114223+
* 21b EPDM
116183+ 116183+ 116184+ 116184+ 116184+ POA
FKM
115626+ 115626+ 116185+ 116185+ 116185+ POA
* 25 O-ring, Non-Flush EPDM
E70115 E70115 E70121 E70121 E70121 E70121
FKM
V70115 V70115 V70121 V70121 V70121 V70121
* 26 O-ring, outer stem (qty 2) Nitrile
N90016 N90016 N90020 N90020 N90020 N90020
PL5027-CH49
Wiping Stem Seal, Upper
16b.2
2
Part Description
Contact Factory
See actuator parts list
*
*
Seat Ring -Tri Ring,
Upper
Seat Ring -Tri Ring,
Lower
O-Ring, Tef Flow® P
Design
Seat Ring -Tri Ring, Vent
Wiping Stem Seal, Lower
