SPX FLOW W70 Series User Manual

Waukesha Cherry-Burrell
®
Brand W70 Series Mix Proof Valves Parts Lists
10/2023 95-03087 Page 47
W71 Mix Proof Non-Seat Lift Valve
Notes:
* Recommended Spare Parts
2. For one-piece body, qty. 2 are required for item 6 and item 18; for a clamped body, qty. 3 are required.
3. For valve with Tef Flow® P design stem only.
4. Unless otherwise noted, quantity required is 1.
6. POA = Part # on availability; N/A = not available with this design.
7. Part number includes lower stem and stem bushing, which are assembled together.
Item # 1-1/2" 2" 2-1/2" 3" 4" 6"
Notes
1 Control Top
3 Actuator
* 4 O-ring, Inner Stem Nitrile N70010 N70010 N70111 N70111 N70111 N70111
* Bearing, Upper Adapter Std. 106047+ 101995+
Tef Flow® P design
102002+ N/A 3
* 6 O-ring, Body EPDM E70223 E70228 E70232 E70236 E70244 E70258
FKM V70223 V70228 V70232 V70236 V70244 V70258
8a Stem, Upper 116615+ 115788+ 115663+ 115648+ 115793+ POA
8b Stem, Upper, Tef Flow® P Design 134818+ 130248+ 130249+ 130250+ 132241+ POA
3
* 10a EPDM 106031+ 102736+ 107048+ 102488+ 102491+ 102738+
FKM 107990+ 107980+ 107982+ 107974+ 107977+ 108020+
*
10b
Seat Ring Insert- Upper Tef Flow® P 130231+ 130232+ 130233+ 130234+ 130235+ POA
3
* 11 EPDM 106041+ 107693+ 107696+ 107697+ 102490+ 102737+
FKM 107992+ 107984+ 107987+ 107988+ 107976+ 108019+
* 12a Seat Ring -Tri Ring, Lowe
r
EPDM 106036+ 107693+ 102487+ 102489+ 102492+ 102739+
FKM 107991+ 107984+ 107973+ 107975+ 107978+ 108021+
* 12b Seat Ring Insert - Lower Tef Flow® P 130243+ 130244+ 130245+ 130246+ 130247+ POA
3
* 14a
Quad Ring, Lower EPDM 122689+ 35413+ 34429+ 117561+ 116952+ 122350+
FKM 122690+ 35414+ 35415+ 117562+ 116953+ 122351+
*
14b
EPDM 116186+ 116188+ 116190+ 116195+ 116199+ POA
FKM 116187+ 116189+ 116191+ 116196+ 116200+ POA
* 15 Bearing, Lower Seal Retainer 101947+ 102000+ 106049+ 106048+ 102003+ 102004+
16a Stem, Lower Assembly 118150+ 118151+ 118152+ 118153+ 118154+ POA
7
16b Stem, Lower, Tef Flow® P Design 131823+ 131824+ 131825+ 131826+ 131827+ POA
3
16b.1 Lower Balancer, Tef Flow® P Design 128919+ 128920+ 128921+ 127704+ 128923+ POA
3
16b.2 EPDM E70210 E70217 E70217 E70217 E70217 POA
3
FKM V70210 V70217 V70217 V70217 V70217 POA
3
17a Seal Retainer, Quad Ring 106066+ 106067+ 106068+ 106069+ 106070+ 125047+
17b Seal Retainer, Wiping Stem Seal 117444+ 117445+ 117446+ 117447+ 117448+ POA
18 Clamp 119-30 119-33 119-34 119-51 119-87 119-123
2
20a/c Adapter, O-ring or Quad Ring 111043+ 111017+ 111196+ 111026+ 111029+ 123970+
20b Adapter, Wiping Stem Seal 117840+ 117841+ 117842+ 117843+ 117878+ POA
* 21a
O-ring, Upper Stem EPDM E70210 E70210 E70214 E70214 E70214 N/A
FKM V70210 V70210 V70214 V70214 V70214 N/A
* 21c
Quad Ring, Upper Stem EPDM 121300+ 121300+ 124163+ 124163+ 124163+ 114221+
FKM 124088+ 124088+ 121299+ 121299+ 121299+ 114223+
*
21b
EPDM 116183+ 116183+ 116184+ 116184+ 116184+ POA
FKM 115626+ 115626+ 116185+ 116185+ 116185+ POA
25 O-ring, Non-Flush EPDM E70115 E70115 E70121 E70121 E70121 E70121
* FKM V70115 V70115 V70121 V70121 V70121 V70121
PL5027-CH47
Part Description
Contact Factory
See actuator parts list
5
102757+ 102757+ 106047+ 106047+
O-Ring, Tef Flow® P
Design
Wiping Stem Seal, Upper
Seat Ring -Tri Ring,
Upper
Seat Ring -Tri Ring, Vent
Wiping Stem Seal, Lower
2
