SPX FLOW W70 Series User Manual

Waukesha Cherry-Burrell
®
Brand W70 Series Mix Proof Valves Parts Lists
10/2023 95-03087 Page 85
W71/W73 Non-Seat Lift Actuator
Notes:
* Recommended Spare Parts
1. 4-inch diameter actuator for 1-1/2" and 2" valves; 6" diameter actuator for 2-1/2", 3"and 4" valves; 8" diameter for 6"
valves.
2. Only required for valves without control top.
3. Item 31 is required on 1-1/2" valves only.
4. Unless otherwise noted, quantity required is 1.
Item # Part Description
4" Diameter
1
6" Diameter
1
8" Diameter
1
1 Indicator Stem - Visual (see note 2)
106050+ 107951+ POA
1a Indicator Stem - Control Top
106003+ 106004+ 110800+
4 Cylinder
106006+ 106007+ 128394+
* 5 Bearing, Indicator Stem
102757+ 102757+ 102757+
* 6 O-ring, Indicator St
e
Nitrile
N70210 N70210 N70210
* 7 O-ring, Outer Yoke Nitrile
N70240 N70255 N70367
* 8 O-ring, Piston Nitrile
N70342 N70433 N70443
9 Cap Screw, 1/4-20 x .375" lg.
30-68
(qty 4 req)
30-68
(qty 8 req)
30-361
(qty 12 req)
10 1-1/2" Valve
132891+ -- --
2" Valve
132388+ -- --
2 1/2",3",4" Valve
-- 132193+ --
6'' Valve
-- -- 129822+
10a 1-1/2" Valve
132671+ -- --
2" Valve
132387+ -- --
2 1/2",3",4" Valve
-- 132192+ --
6'' Valve
-- -- POA
* 11 O-ring, Yoke Nitrile
N70210 N70214 N70214
12 Yoke 1-1/2" Valve
106119+ -- --
2" Valve
107764+ -- --
2 1/2" Valve
-- 106120+ --
3" Valve
-- 106121+ --
4" Valve
-- 106118+ --
6'' Valve
-- -- 128396+
13 Vent Plug (see note 2)
3023957+ 3023957+ 3023957+
* 14 Bearing, Piston
101995+ 102052+ 100256+
* 15 Bearing, Yoke
102757+ 106047+ 106047+
18 Spring, Upper Stem
101946+ 5901106+ 5901106+
31 Washer (see note 3)
43-55 -- --
33
Elbow swivel 90°
78-157 78-157 78-157
Actuator Seal Kit (contains recomm. spares) 129866+ 129867+ --
4" Diameter
1
6" Diameter
1
8" Diameter
1
1-1/2" Valve ACT00188 -- --
2" Valve ACT00122 -- --
2 1/2" Valve -- ACT00279 --
3" Valve -- ACT00280 --
4" Valve -- ACT00281 --
6'' Valve -- -- POA
PL5027-CH58
Lower Seat Piston &
Spring Assembly,
Tef-Flow™ P Design
Only
Piston & Spring
Assembly
Complete Actuator Assemblies
Air-to-Raise, Visual Indicator
Stem
Part Description
