1. 4-inch diameter actuator for 1-1/2" and 2" valves; 6" diameter actuator for 2-1/2", 3"and 4" valves; 8" diameter for 6"
valves.
2. Only required for valves without control top
3. Item 31 is required on 1-1/2" valves only.
Item #
4" Diameter
1
6" Diameter
1
8" Diameter
1
1
106050+ 107951+ POA
1a Indicator Stem - Control Top
106003+ 106004+ POA
4 Cylinder
106006+ 106007+ 128394+
* 5 Bearing, Indicator Stem
102757+ 102757+ 102757+
* 6 O-ring, Indicator Stem Nitrile
N70210 N70210 N70210
* 7 O-ring, Cylinder Nitrile
N70240 N70255 N70367
* 8 O-ring, Piston Nitrile
N70342 N70433 N70443
9 Cap Screw, 1/4-20 x .375" lg.
30-68 (4 req) 30-68 (8 req) 30-361 (12 req)
Piston & Spring Assembly 1-1/2" Valve
132891+ -- --
2" Valve
132388+ -- --
2 1/2", 3", 4" Valve
-- 132193+
6'' Valve
-- -- POA
* 11 O-ring, Yoke Nitrile
N70210 N70214 N70214
12 Yoke 1-1/2"
106119+ -- --
2"
107764+ -- --
2-1/2"
-- 106120+ --
3"
-- 106121+ --
4"
-- 106118+ --
6''
-- -- 128396+
13 Vent Plug (see note 2) 3023957+ 3023957+ 3023957+
*
14 Bearing, Piston
101995+ 102052+ 100256+
*
15 Bearing, Yoke
102757+ 106047+ 106047+
18 Spring, Upper Stem 101946+ 5901106+ 5901106+
31 Washer (see note 3) 43-55 -- --
32 Spring Guide 118459+ 118529+ POA
33 Elbow swivel 90°
78-157 78-157 78-157
Actuator Seal Kit (contains recomm. spares)
129866+ 129867+ --
For Valve Size
4" Diameter
1
6" Diameter
1
8" Diameter
1
Air-to-Raise Visual Indicator Stem
1-1/2" ACT00342 -- --
2" ACT00343 -- --
2-1/2" -- ACT00344 --
3" -- ACT00345 --
4" -- ACT00346 --
6" -- -- POA
Control Top Indicator Stem 1-1/2" ACT00352 -- --
2" ACT00353 -- --
2-1/2" -- ACT00354 ACT00354
3" -- ACT00355 ACT00355
4" -- ACT00356 ACT00356
6" -- -- POA
PL5027-CH62
Part Description
Indicator Stem - Visual (see note 2)
Part Description
Complete Actuator Assemblies
10
