Chapter 3. Identifying the Components
May 2002 T-38324-A Page 3-7
Figure 3-4. Components Inside the Enclosure of the CS4000
Mini Controller with Ethernet
NOTE: The AC power cord is described in Top and Bottom Panel earlier
in this chapter.
Backplane
Ethernet Interface
Card
Exterior Wall
AC Power Cord
Tool Control
Module
Power Supply
Interbus-S Module
(Optional)
