Chapter 6. Setting Up a 485 Network
May 2002 T-38324-A Page 6-5
Table 6-2. Setting Address Switches (continued)
To set the following
address number:
Set these Address
switches ON:
Keep these DIP
switches OFF
Address 7 1, 2, 3 4, 5, 6, 7, 8
Address 8 4 1, 2, 3, 5, 6, 7, 8
Address 9 1, 4 2, 3, 5, 6, 7, 8
Address 10 2, 4 1, 3, 5, 6, 7, 8
Address 11 1, 2, 4 3, 5, 6, 7, 8
Address 12 3, 4 1, 2, 5, 6, 7, 8
Address 13 1, 3, 4 2, 5, 6, 7, 8
Address 14 2, 3, 4 1, 5, 6, 7, 8
Address 15 1, 2, 3, 4 5, 6, 7, 8
Address 16 5 1, 2, 3, 4, 6, 7, 8
Address 17 1, 5 2, 3, 4, 6, 7, 8
Address 18 2, 5 1, 3, 4, 6, 7, 8
Address 19 1, 2, 5 3, 4, 6, 7, 8
Address 20 3, 5 1, 2, 4, 6, 7, 8
Address 21 1, 3, 5 2, 4, 6, 7, 8
Address 22 2, 3, 5 1, 4, 6, 7, 8
Address 23 1, 2, 3, 5 4, 6, 7, 8
Address 24 4, 5 1, 2, 3, 6, 7, 8
Address 25 1, 4, 5 2, 3, 6, 7, 8
Address 26 2, 4, 5 1, 3, 6, 7, 8
Address 27 1, 2, 4, 5 3, 6, 7, 8
Address 28 3, 4, 5 1, 2, 6, 7, 8
Address 29 1, 3, 4, 5 2, 6, 7, 8
Address 30 2, 3, 4, 5 1, 6, 7, 8
Address 31 1, 2, 3, 4, 5 6, 7, 8
Address 32 6
Using the information in Table 6-2, Figure 6-2 shows you how to set address ‘5.’
12345678
ON
↑
Figure 6-2. Network Address DIP Switch Set for Address ‘5’
