CS4000 Mini Controller with Ethernet
Page
3-8
T-38324-A 39-30-38324
Tool Control Module
The Tool Control Module (TCM), shown in Figure 3-5, is a device that controls a single DC electric
tool. The TCM and its attached tool are referred to as a spindle. The TCM houses both the servo
amplifier and Device Control Module (DCM). For the location of the TCM inside the CS4000 Mini
Controller with Ethernet, see Figure 3-4 on page 3-7.
Figure 3-5. Front View of the TCM
Side Panel
Front Panel
Thumbscrews
