Figure 5 - Common Part Identification
Introduction Waukesha Cherry-Burrell
Page 12 95-03080 12/2010
Table 3: Callout Table for Figure 5
A. Motor Shims L. Tabbed Washer
B. Slinger M. O-ring
C. L-gasket N. Rotary Seal
D. Stationary Seal P. Stationary Seal
E. Rotary Seal R. L-gasket
F. O-ring S. O-ring
G. Tabbed Washer T. Housing
H. Springs U. O-ring
J. Spring Retainer V. Seat Retainer
K. Springs W. Cap Screws
