SPX S2045 - Basic Seal Kit - Type 4 Seal - Sanitary Pump Model; Complete Seal Kit - Type 4 Seal - Sanitary Pump Model

Parts Lists Waukesha Cherry-Burrell
Page 50 95-03080 12/2010
Basic Seal Kit - Type 4 Seal - Sanitary Pump Model
KIT CONTAINS QTY
MODEL
S2045 S2065* S2075 S2085* S2092
CARBON SEAL (FKM & EPDM) 2 9-225A 9-225A 9-225A 9-225A 9-225A
SEAL O-RING (FKM) 2 V70224 V70224 V70224 V70224 V70224
SEAL O-RING (EPDM) 2 E70224 E70224 E70224 E70224 E70224
CASING O-RING (FKM) 1 V70252 V70439 V70446 V70446 V70373
CASING O-RING (EPDM) 1 E70252 E70439 E70446 E70446 E70373
IMPELLER O-RING (FKM) 1 V70214 V70220 V70220 V70220 V70220
IMPELLER O-RING (EPDM) 1 E70214 E70220 E70220 E70220 E70220
HOUSING O-RING (FKM) 2 V70039 V70039 V70039 V70039 V70039
HOUSING O-RING (EPDM) 2 E70039 E70039 E70039 E70039 E70039
KIT ORDER # (FKM) 309-249 309-250 309-251 309-251 309-269
KIT ORDER # (EPDM) 309-249E 309-250E 309-251E 309-251E POA
Complete Seal Kit - Type 4 Seal - Sanitary Pump Model
KIT CONTAINS QTY
MODEL
S2045 S2065* S2075 S2085* S2092
CARBON SEAL (FKM & EPDM) 2 9-225A 9-225A 9-225A 9-225A 9-225A
SEAL O-RING (FKM) 2 V70224 V70224 V70224 V70224 V70224
SEAL O-RING (EPDM) 2 E70224 E70224 E70224 E70224 E70224
CASING O-RING (FKM) 1 V70252 V70439 V70446 V70446 V70373
CASING O-RING (EPDM) 1 E70252 E70439 E70446 E70446 E70373
IMPELLER O-RING (FKM) 1 V70214 V70220 V70220 V70220 V70220
IMPELLER O-RING (EPDM) 1 E70214 E70220 E70220 E70220 E70220
HOUSING O-RING (FKM) 2 V70039 V70039 V70039 V70039 V70039
HOUSING O-RING (EPDM) 2 E70039 E70039 E70039 E70039 E70039
STATIONARY SEAL (FKM & EPDM) 2 23-17 23-17 23-17 23-17 23-17
L - GASKET (FKM & EPDM) 2 9-37 9-37 9-37 9-37 9-37
KIT ORDER # (FKM) 309-253 309-254 309-255 309-255 309-270
KIT ORDER # (EPDM) 309-253E 309-254E 309-255E 309-255E POA
*Includes LV and HV models
