ITEM # 20RA 15RA 15RA EP 20RA EP
S2045 1515 Solid Bar Casing S-Line CENTPT00501 CENTPT00015 CENTPT00014 CENTPT00016
Buttweld CENTPT00502 CENTPT00018 CENTPT00017 CENTPT00019
150# Flange CENTPT00503 CENTPT00021 CENTPT00020 CENTPT00022
DIN CENTPT00504 CENTPT00024 CENTPT00023 CENTPT00025
S2045 2015 Solid Bar Casing S-Line CENTPT00501 CENTPT00027 CENTPT00026 CENTPT00028
Buttweld CENTPT00502 CENTPT00030 CENTPT00029 CENTPT00031
150# Flange CENTPT00503 CENTPT00033 CENTPT00032 CENTPT00034
DIN CENTPT00504 CENTPT00036 CENTPT00035 CENTPT00037
2
S2045 Impellers Small Bore CENTPT00702 CENTPT00703 CENTPT00704 CENTPT00447
S2045 (129-773X) Retainer Nut
Small Bore (142/184) CENTPT00705 CENTPT00706 CENTPT00707 CENTPT00708
10
Backplate CENTPT00709 CENTPT00710 CENTPT00711 CENTPT00441
C T 10 0 - 18 6 a
DESCRIPTION
1
3
Parts Lists Waukesha Cherry-Burrell
Page 54 95-03080 12/2010
S2045 Components (Close Coupled)
