SPX S2045 - Page 53

Waukesha Cherry-Burrell Parts Lists
12/2010 95-03080 Page 53
Seal Components All Pumps
ITEM # PART #
TYPE 1/1C
SEAL QTY
TYPE 4
SEAL QTY
1
Deflector 69-1 1 -
Stationary Seal Purbide (1.75") 23-17 1 2
Silicone Carbide (1.75") 23-17A 1 2
Ceramic (1.75") 23-17E 1 2
Tungsten Carbide (1.75") 23-17F 1 2
3
Seal Retainer 23-78 1 -
4
1/4 -20 x 1/2" Bolt (4 each) 30-62 4 -
Rotary Seal Carbon (1.75") 9-225A 1 2
Purbide (1.75") 9-225B 1 2
Silicone Carbide (1.75") 9-225C 1 2
Tungsten Carbide (1.75") 9-225F 1 2
*6
1/4-20 x 3/8" Set Screw (2 each) 30-178 2 1
*7
Spring Retainer (1.75") 23-77 1 -
L-gasket
FKM (1.75")
9-37 1 2
EPDM (1.75")
9-37E 1 2
FFKM (1.75")
9-37K 1 2
Silicone
9-37R 1 2
O-ring
FKM (1.75")
V70224 1 2
EPDM (1.75")
E70224 1 2
Chemrez
®
(1.75")
C75224 1 2
FFKM (1.75")
K75224 1 2
Silicone (1.75")
S75224 1 2
*10
Washer, tabbed
43-87 1 2
*11
Spring 24-65 3 6
*12
O-ring, housing V70039 - 2
13
Housing, seal 23-80 - 1
14
Retainer, seat 23-79 - 1
15
1/4-20 x 3" Cap Screw 30-175 4 4
16
Slinger, 142-215JM 69-4 - 1
17
1/4" N.P.T. Plug 78-155 - 1
18
Block, water cascade 134-2 1 -
19
8-32 x 1/4" Socket Head 30-176 2 -
20
1/4" Plastic Hose 74-1 9" -
21
1/4" Hose Fitting 78-18 1 -
Notes
C T 10 0 - 18 5
*
Recommended spare parts
DESCRIPTION
2
*
*
5
9*
*8
