SPX S2045 - Page 57

Waukesha Cherry-Burrell Parts Lists
12/2010 95-03080 Page 57
S2065/S2065LV/S2065HV Components (Close Coupled)
ITEM # PART # QTY
FKM V70220 1
EPDM E70220 1
Silicone S75220 1
FFKM K75220 1
143-184JM Motor Frame 2-168 1
213-215JM Motor Frame 2-169 1
254-256JM Motor Frame 2-170 1
284-326JM Motor Frame 2-196 1
143-215 Motors 70-23 1
254-256 Motors 70-24 1
284-326 Motors 70-26 1
1/2-13 x 1-14" Bolt 213-256JM Motors 30-36X 4
3/8-16 x 1" Bolt 143-184JM Motors 30-30X 4
5/8-11 x 1-1/2" Bolt 284-286JM Motors 30-105 4
3/8" Lock washer 43-28 4
1/2" Lock washer 43-16 4
5/8" Lock washer 43-33 4
FKM V70439 1
EPDM E70439 1
Silicone S75439 1
FFKM K75439 1
11
Casing clamp 119-70 1
Key 3/16" 143-215JM Motor Frame 65-3 1
Key 1/4" 254-326JM Motor Frame 65-4 1
Notes
C T 10 0 - 18 7
*
Recommended spare parts
*
5
6
DESCRIPTION
4
*9
12
7
8
O-ring
Seal Guard (Type 1 Seal)
Adapter
O-ring
