SPX S2045 - Page 63

Waukesha Cherry-Burrell Parts Lists
12/2010 95-03080 Page 63
S2092 Components (Close Coupled)
ITEM # PART # QTY
O-ring FKM V70220 1
EPDM E70220 1
Silicone S75220 1
FFKM K75220 1
Adapter 143-184JM Motor Frame 2-171 1
213-215JM Motor Frame 2-172 1
254-256JM Motor Frame 2-173 1
284JM and Larger Motor Frame 2-174 1
Seal Guard 143-215JM Motors 70-23 1
254-256 JM Motors 70-24 1
284-324JM Motors 70-26 1
284JM and Larger Motors 114508 1
3/8-16 x 1" Bolt 143-184JM Motors 30-30 4
1/2-13 x 1 1/4" Bolt 213-256JM Motors 30-36X 4
5/8-11 x 1-1/2" Bolt 284JM and Larger Motors 30-105 4
3/8" Lock washer 43-28 4
1/2" Lock washer 43-16 4
5/8" Lock washer 43-33 4
O-ring FKM V70373 1
EPDM E70373 1
Silicone S75373 1
FFKM K75373 1
11
Casing clamp 119-69 1
Key 3/16" 143-215JM Frame Motors 65-3 1
Key 1/4" 254-326JM Frame Motors 65-4 1
Notes
C T 10 0 - 19 3
*
Recommended spare parts
DESCRIPTION
4
5
12
*
*
8
9
6
7
