SPX S2045 - Page 69

Waukesha Cherry-Burrell Parts Lists
12/2010 95-03080 Page 69
Pedestal Mounted Pumps - Large Bore
ITEM # STYLE MOTOR PART #
Bearing housing S2065 B,C ALL 68-9
S2075-S2085-S2092 B,C ALL 68-10
2
Shaft B,C ALL 62-539X
*3
Bearing 5311 B,C ALL 23-98
*5
Retaining ring B,C ALL 43-138
6
Seal outer B,C ALL 23-95
7
Seal inner motor end B,C ALL 23-94
8
Seal inner motor impeller end B,C ALL 23-93
*9
035 O-ring inner B,C ALL N70035
*10
033 O-ring inner impeller B,C ALL N70033
11
HHCS 1/2-13 x 3-1/4" ALL ALL 30-221X
13
SHSS 1/4-20 x 3/8" B,C ALL 30-178
14
Grease fitting B,C ALL BD0092000
15
Stand B,C ALL 4-35
16
HHCS 1/2-13 x 1-1/4" B,C ALL 30-36X
*17
045 O-ring outer B,C ALL N70045
18
Seal Guard S2065-S2085 B,C ALL 70-33
19
Cover coupling adapter B ALL 70-34
20
Cover coupling L.H. C ALL 70-35
21
Cover coupling R.H. C ALL 70-36
22
Brace, cover coupling C ALL 2-252
23
HHCS 1/4-20 x 1/2" LG. B,C ALL 30-62
B 213TC 2-249
*
B 215TC 2-249
B 254TC 2-249
B 256TC 2-249
B 284TC 2-250
B 286TC 2-250
B 324TC 2-250
B 326TC 2-250
B 364TC 2-250
B 365TC 2-250
B 254TC 43-134
B 256TC 43-134
B 324TC 43-136
B 326TC 43-136
B,C 364TC 43-137
B,C 365TC 43-137
26
End cap housing LB C ALL 23-97
Notes
CT100-190
*
Recommended spare parts
DESCRIPTION
1
24
25
Spacer adapter
Adapter
