SPX S2045 - Page 71

ITEM # STYLE MOTOR PART #
1.375 6S B,C 213-215 33220+
1.625 7S B,C 254-256 33227+
1.875 7S B,C 284/286 33229+
2.125 8S B,C 324-326 33237+
2.375 8S B,C 364 11-107
2.375 8S B,C 365 11-107
6JES B,C 213/215 11-31
7JES B,C 254/286 11-32
8JES B,C 324/326 11-33
8HSS B,C 364/365 33189+
1.250 6S B,C 213/215 33219+
1.250 7S B,C 254/286 33224+
1.250 8S B,C 324/365 33230+
1/2-13 x 1-1/4" B 213/215 30-36X
1/2-13 x 1-1/4" B 324/365 30-21
32
HHCS 1/2-13 x 1-1/2" B,C ALL 30-103X
33
Washer 1/2" B,C ALL 43-31X
34
Lock washer 1/2" B,C ALL 43-16
35
SHCS 1/4-20 x 1-1/2" B,C ALL 30-222X
36
Adapter, cartridge seal B,C ALL 23-91X
37
HHCS 1/2-13 x 1-3/4" B,C ALL 30-127X
38
Flat washer 1/2" B,C ALL 43-31X
FKM B,C ALL 9-37
EPDM B,C ALL 9-37E
FFKM B,C ALL 9-37K
Notes
C T 10 0 - 19 0 a
*
Recommended spare parts
*
*28
Coupling sleeve
29
Coupling half
30
HHCS
L-gasket
DESCRIPTION
39
27
Coupling half
Waukesha Cherry-Burrell Parts Lists
12/2010 95-03080 Page 71
Pedestal Mounted Pumps Large - Bore, cont’d
