SRAM Rockshox Recon Series User Manual

19
Exploded View - 2021 Recon Gold RL - DebonAir
Exploded View - 2021 Recon Gold RL - DebonAir
Retaining screw
Compression damper top cap
Compression damper
Crown
Dust wiper seal
Foam ring
Rebound damper piston
Rebound damper shaft
Rebound damper deal head
Maxle Stealth
Crush washer
Bottom bolt
Rebound adjuster knob
Steerer tube
Air valve
Air spring top cap
Bottomless Token 32 mm black (optional)
Upper tube
Air spring piston
Top out bumper
Lower leg
Retaining washer
Wave spring
Negative air piston
Air Spring Assembly
Compression Damper
Assembly
Rebound Damper
Assembly
Brake hose guide
Detent spring
Crush washer retainer
All-Travel spacer (optional)
Base plate
Retaining ring
Retaining ring
Compression adjuster knob
Air cap
Set screw
2021 Recon Gold RL R
Retaining screw
Remote spool
Cable stop collar
Set screw
Arch
