SRAM Rockshox Recon Series User Manual

24
Exploded View - 2020 Recon TK (Boost) / 2021 Recon Silver TK (Boost) - Coil
Exploded View - 2020 Recon TK (Boost) / 2021 Recon Silver TK (Boost) - Coil
Retaining screw
Steerer tube
2020-2021 Recon TK R
Compressionadjuster knob
Crown
Compression damper
Dust wiper seal
Foam ring
Rebound damper piston
Rebound damper shaft
Rebound damper seal head
Retainer
Maxle Stealth
Rebound adjuster knob
Retaining screw
Preload adjuster knob
Upper tube
Coil spring assembly
Coil spring isolator
Coil spring shaft
Crush washer
Bottom bolt
Retaining screw
Remote cable
stop collar
Coil Spring Assembly
Compression Damper
Assembly
Rebound Damper
Assembly
Brake hose guide
Set screw
Set screw
Remote spool
Crush washer retainer
Lower leg
Arch
Retainer
Compression damper top cap
