All-Travel Spacer Configurations (optional)
All-Travel Spacer Configurations (optional)
To increase or decrease the travel of your RockShox fork, an All-Travel spacer can be installed or removed. For example, to increase travel from a
maximum of 130 mm of travel to a maximum of 150 mm of travel, the 20 mm All-Travel spacer must be removed from the air spring assembly.
If travel is changed from 80 mm, 100 mm, or 120mm to 130 mm, 140 mm, or 150 mm, and vice versa, the air spring must be replaced with the
appropriate length air spring assembly in addition to the appropriate length All-Travel spacer.
Use the table and images below to determine which All-Travel spacer and air spring assembly can be used with each fork travel option.
Refer to the RockShox Spare Parts Catalog at www.sram.com/service for available air springs and All-Travel spacer kits.
For part ordering information, please contact your local SRAM distributor or dealer.
NOTICE
Do not install All-Travel spacers larger than the largest specified spacer for your fork.
Do not install an air spring assembly that exceeds the maximum travel specified for your fork.
All-Travel Spacers - Judy Gold, 30 Gold, Recon Gold - Solo Air
Wheel Size
26" 27.5" 27.5" Boost 29" 29" Boost
Fork Model Travel All-Travel Spacer
2018-2021
Judy Gold
80 mm 20 mm 40 mm 40 mm 40 mm 40 mm
100 mm No Spacer 20 mm 20 mm 20 mm 20 mm
120 mm - No Spacer No Spacer No Spacer No Spacer
2018-2020
30 Gold
80 mm 20 mm 40 mm - 40 mm -
100 mm No Spacer 20 mm - 20 mm -
120 mm - No Spacer - No Spacer -
2018-2020
Recon Gold
80 mm - 40 mm 40 mm 40 mm 40 mm
100 mm - 20 mm 20 mm 20 mm 20 mm
120 mm - No Spacer No Spacer No Spacer No Spacer
130 mm - 20 mm 20 mm 20 mm 20 mm
140 mm - - 10 mm - 10 mm
150 mm - - No Spacer - -
