SRAM Rockshox Recon Series User Manual

22
Exploded View - 2020 Recon RL (Boost) / 2021 Recon Silver RL (Boost) - Solo Air
Exploded View - 2020 Recon RL (Boost) / 2021 Recon Silver RL (Boost) - Solo Air
Retaining screw
2020-2021 Recon RL R
Compression adjuster knob
Detent spring
Crown
Compression damper
Dust wiper seal
Foam ring
Rebound damper piston
Rebound damper shaft
Rebound damper seal head
Retainer
Maxle Stealth
Rebound adjuster knob
Steerer tube
Air cap
Air valve
Air spring top cap
Upper tube
Air tube
Air spring piston
Top out bumper
All-Travel spacer (optional)
Seal head
Air spring shaft
Crush washer
Bottom bolt
Retaining screw
Remote cable
stop collar
Air Spring Assembly
Compression Damper
Assembly
Rebound Damper
Assembly
Brake hose guide
Set screw
Set screw
Remote spool
Crush washer retainer
Lower leg
Arch
