SRAM Rockshox Recon Series User Manual

89
Lower Leg Assembly
Lower Leg Assembly
50/200 Hour Service Lower Leg Installation
Clean the upper tubes.
Install the lower leg assembly onto the upper tubes and slide it just
enough to engage the upper bushings with the upper tubes.
NOTICE
Make sure both wiper seals slide onto the tubes without folding the
outer lip of either seal.
The inside bottom of the lower leg should not contact the spring or
damper shafts. A gap between the shaft ends and the lower leg bolt
holes should be visible.
1
2
