Air Spring Installation - Silver
200 Hour Service Air Spring Installation - Silver
NOTICE
Inspect each part for scratches. Do not scratch any sealing surfaces when
servicing your suspension. Scratches can cause leaks.
When replacing seals and o-rings, use your fingers or a pick to remove the
seal or o-ring. Spray isopropyl alcohol on each part and clean with a clean
lint-free shop towel.
Apply Liquid-O-Ring PM600 or SRAM Butter grease to the new seals and
o-rings. If a brush is used to apply grease, confirm there are no loose
bristles in the grease or on the part.
Apply grease to the air shaft.
Install the top out bumper, All-Travel spacer (A) if originally equipped or
added if travel is reduced, and the negative air assembly onto the air
shaft.
Apply grease to the inside of one end of the air tube, approximately
60 mm into the tube.
1
A
2
