Air Spring Service - Judy Gold, 30 Gold, Recon Gold
Air Spring Service - Judy Gold, 30 Gold, Recon Gold
200 Hour Service Air Spring Removal and Service - Gold
⚠ WARNING EYE HAZARD
Verify all pressure is removed from the fork before proceeding. Depress the Schrader valve again to remove any remaining air pressure. Failure to
do so can result in injury and/or damage to the fork.
NOTICE
Inspect each part for scratches. Do not scratch any sealing surfaces when
servicing your suspension. Scratches can cause leaks.
When replacing seals and o-rings, use your fingers or a pick to remove the
seal or o-ring. Spray isopropyl alcohol on each part and clean with a clean
lint-free shop towel.
Apply Liquid-O-Ring PM600 or SRAM Butter grease to the new seals and
o-rings. If a brush is used to apply grease, confirm there are no loose
bristles in the grease or on the part.
Remove the air spring top cap.
Clean the upper tube threads.
Push the air shaft into the upper tube to prevent it from getting
scratched while removing the retaining ring.
1
2
