Air Spring Removal and Service - Silver
200 Hour Service Air Spring Removal and Service - Silver
⚠ WARNING EYE HAZARD
Verify all pressure is removed from the fork before proceeding. Depress the Schrader valve again to remove any remaining air pressure. Failure to
do so can result in injury and/or damage to the fork.
NOTICE
Inspect each part for scratches. Do not scratch any sealing surfaces when
servicing your suspension. Scratches can cause leaks.
When replacing seals and o-rings, use your fingers or a pick to remove the
seal or o-ring. Spray isopropyl alcohol on each part and clean with a clean
lint-free shop towel.
Apply Liquid-O-Ring PM600 or SRAM Butter grease to the new seals and
o-rings. If a brush is used to apply grease, confirm there are no loose
bristles in the grease or on the part.
Unthread the air spring top cap from the upper tube.
The air spring tube is attached to the top cap. Remove the top cap, air
tube and air spring assembly from the upper tube.
Clean the upper tube threads.
Remove the top cap.
Remove the air spring assembly from the air tube.
1
2
3
