SRAM Rockshox Recon Series User Manual

54
Air Spring Installation - Silver
Inject or pour RockShox suspension oil into the air spring tube.
Oil Weight (wt)
Air Spring
Volume (mL)
Judy Silver
5 230 Silver
Recon Silver RL
Install the air top cap into the air tube.
Apply a small amount of grease to the top cap threads.
Insert the air assembly, shaft first, into the top of the upper tube.
Guide the air shaft through the shaft guide in the bottom of the upper
tube.
Thread the top cap into the upper tube and tighten it. Press down
firmly when tightening the top cap.
200 Hour Service Continue the 200 Hour Service with Damper Service - Judy Silver, 30 Silver, Recon Silver RL, Recon Silver TK.
5
5wt RockShox bleed syringe
6
7
8
24 mm 12.4 N·m (110 in-lb)
