6-12
TRANSMISSION AND BRAKE SYSTEM
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Obstacle Detecting Sensor
When you move the gear selector
lever to “R”, the alarm sounds ac-
cording to the distance from ob-
stacle to vehicle.
PARKING AID SYSTEM
When the gear selector lever is shifted into “R”, the parking aid
system is activated and the sensors in the rear bumper detect
the distance to any obstacle. You can figure out the distance from
the obstacle to your vehicle by the alarming sound. The alarm in-
terval becomes faster as your vehicle approaches the object.
Obstacle Detecting
Sensor
Alarm interval
no alarm
approx. 2.6 sec
approx. 1.3 sec
alarm stays on
Distance
over 1.2 m
80 cm ~ 1.2 m
51 cm ~ 80 cm
25 cm ~ 50 cm
ACTYON
Alarm interval
no alarm
approx. 2 sec
approx. 0.7 sec
alarm stays on
Distance
over 1.2 m
90 cm ~ 1.2 m
60 cm ~ 90 cm
25 cm ~ 60 cm
ACTYON SPORTS
• The alarm does not sound if the distance between sen-
sor and obstacle is less than 25 cm. However, if the sen-
sor detects the obvious obstacle, the alarm stays on.
• Do not rely on the parking aid system while gear selector
lever is in “R” position. Drive backward while checking
the rear side of your vehicle.
• If the buzzer sounds abnormally or sounds for over 3
seconds when placing the gear selector lever to “R”
position, the parking aid system is defective. Have the
system checked at Ssangyong Dealer or Ssangyong Au-
thorized Service center.
CAUTION
Q100-06-Transmission and Brake System.p65 2006-10-02, ¿ÀÈÄ 3:07Page 12 Adobe PageMaker 6.5K/Win
