SSANGYONG ACTYON - Coolant Temperature Gauge; Fuel Gauge

INSTRUMENT CLUSTER
5-4
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
COOLANT TEMPERATURE GAUGE
The temperature gauge indicates the temperature of the en-
gine coolant.
The engine can overheat.
• If the pointer reaches the red zone, stop the vehicle.
• Allow engine to cool.
If the engine is overheated, continued operation of the vehicle
may seriously damage the engine.
CAUTION
FUEL GAUGE
This gauge indicates the level of fuel remaining in the fuel
tank. Fill up the fuel tank before the needle reaches “E”.
