INSTRUMENT CLUSTER
5-3
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
TACHOMETER
The tachometer indicates engine speed in revolutions per
minute. Multiply 1,000 to the current number, then it will be
the current number of engine revolutions.
Specified idle rpm
Do not let engine reach excessive speed, indicated by the pointer
being in the red zone.
WARNING
Diesel Gasoline
Diesel
Gasoline
780 ± 50 rpm
750 ± 50 rpm
SPEEDOMETER
The speedometer indicates the vehicle speed in kilometers
per hour (km/h).
NOTE
RED ZONE
(GCC ONLY)
Speedometer-KPH (MPH) Speedometer-MPH (KPH)
